28
5.4 Custom unit
Custom unit allows the creation of your own custom weighing units. It permits entering a conversion factor which the
balance will use to convert grams to the desired unit of measure. Custom Units are stored in the Library. Values for
up to fifteen different custom units can be entered.
Conversion Factor x Weight in grams = Weight in custom unit
Conversion factors are expressed in scientific notation and entered into the balance in three parts:
1) a number between 0.1 and 1.999999 called the mantissa
2) a power of 10 called the exponent
3) a least significant digit (LSD)
SCIENTIFIC NOTATION
Number
Between
Conv. 0.1 and Power Man-
Factor 1.999999 of 10 tissa Exp.
123.4 = .1234 x 1000 = .1234 x 10 3
12.34 = .1234 x 100 = .1234 x 10 2
1.234 = .1234 x 10 = .1234 x 10 1
.1234 = .1234 x 1 = .1234 x 10 0
.01234 = .1234 x .1 = .1234 x 10 -1
.001234 = .1234 x .01 = .1234 x 10 -2
.000123 = .123 x .001 = .123 x 10 -3
Scroll to SETUP and press Enter button. UNIT NAME is displayed.
Enter
From main menu
Select CHANGE UNITS. Scroll to CUSTOM UNITS and press Enter button. The
display indicates GO TO LIBRARY. CUSTOM UNITS
GO TO LIBRARY
SETUP
EXIT TO WEIGH
When using the balance for the first time, the library is empty and does not
contain any custom units. Later, after you have performed the setup proce-
dures, you will be able to select a custom unit by a name you have as-
signed. Proceed to SETUP.
Enter
CUSTOM UNITS
GO TO LIBRARY
SETUP
EXIT TO WEIGH
EXPONENTS
E-3 Moves decimal point 3 places to the left.
E-2 Moves decimal point 2 places to the left.
E-1 Moves decimal point 1 place to the left.
E0 Leaves decimal point in normal position.
E1 Moves decimal point 1 place to the right.
E2 Moves decimal point 2 places to the right.
E3 Moves decimal point 3 places to the right.
