52
TARE SELECTION
NO TARE
MEAN TARE
INDIVIDUAL TARE
ADD. WITH MT
RETURN TO SETUP
Specifying batch name
Enter BATCH NAME. Specify the name of the batch and press Enter button.
After specifying the batch name, the display advances to SQC SETUP with
RUN highlighted. You are now ready to take samples.
SQC SETUP
LIBRARY NAME SQC1
TOLERANCE
TARE NO TARE
MEAN TARE VALUE OFF
AUTO SAMPLE OFF
AUTO PRINT OFF
NUMBER OF SAMPLES I
BATCH NAME
Selecting auto sample/auto print
AUTO SAMPLE and AUTO PRINT are ON/OFF selectable functions. When
AUTO SAMPLE is turned ON, samples can be taken without pressing any
buttons. When AUTO PRINT is set ON, automatic printing of results are
made. Select functions and press Enter button.
SQC SETUP
LIBRARY NAME SQC1
TOLERANCE
TARE NO TARE
MEAN TARE VALUE OFF
AUTO SAMPLE OFF
AUTO PRINT OFF
NUMBER OF SAMPLES 3
BATCH NAME
Specifying sample size
Enter NUMBER OF SAMPLES. Specify the number of samples to be mea-
sured. After specifying sample size, display advances to SQC SETUP with
BATCH NAME highlighted. Press Enter button.
SQC SETUP
LIBRARY NAME SQC1
TOLERANCE
TARE NO TARE
MEAN TARE VALUE OFF
AUTO SAMPLE OFF
AUTO PRINT OFF
NUMBER OF SAMPLES 3
BATCH NAME
Selecting type of tare
Four types of taring are available. NO TARE is self explanatory, MEAN TARE
is used to subtract the packaging weight automatically, INDIVIDUAL TARE is
for each sample with display prompts, ADD with MT is additive weighing
with
mean tare. After selecting tare type, press Enter button.
SQC SETUP
Taking samples
The balance has a total limit of 5 history files which can include other
functions such as Differential Weighing and Formulation. If more than five
sets are entered, one or more data files will have to be removed. If when
saving, a message appears FAILED TO SAVE, the library is full.
AUTO SAMPLE OFF
AUTO PRINT OFF
NUMBER OF SAMPLES 3
BATCH NAME 0
V IEW MEAN VALUE TRACE
VIEW BATCH HISTORY
RUN
0.000
START/SAMPLE SETUP MAIN MENU
SQC - - SQC2
0% 100%
PUT SAMPLE #1 ON PAN
Sample # 1
With the SQC SETUP displayed and RUN highlighted, press Enter button,
display indicates the previously entered data Library name at the right hand
top of the display and instructs: PUT SAMPLE #1 ON PAN.
11.905
START/SAMPLE SETUP MAIN MENU
SQC - - SQC2
0% 100%
PUT SAMPLE #1 ON PAN
Place your first sample on the balance pan, then press Enter button. When
the balance stabilizes, it will record the weight you have placed on the pan
and will automatically advance to sample number 2.
Balance modes
