24
3.12 Quick Check Weighing
Quick check weighing permits you to place a reference sample or a sample weight on the balance pan which is used
as a reference weight to measure against similar samples. A single bar display indicates up to 100% of the capacity
of the balance, the difference in weight between the original sample and suceeding samples is displayed. The
difference in percentage is also shown along with the reference weight. The large numeric display indicates the
weight of the subject.
Go Back
Help
Print Enter
MAIN MENU
CHANGE UNITS SET BALANCE
LIBRARY CALIBRATION CUSTOM MENU
CHANGE MODE
Procedure
• Press arrow button to select MAIN MENU.
• Press Enter button.
• Using the arrow buttons, select CHANGE MODE.
• Press Enter button.
• Press or arrow button and select QUICK
CHECK.
• Press Enter button.
• Place the reference weight on the pan and press the
Enter button.
• Remove reference weight from the pan and place
sample to be compared against the reference weight
on the pan.
• The balance displays the difference of the sample
weight against the reference weight in a measuring
unit and percentage. The bar graph indicates the
percentage of weight of the capacity of the balance.
• To enter a new reference weight, select NEW at the
bottom of the display using the arrow button and
press the Enter button and repeat procedure.
Go Back
Help
Print Enter
0.00
WEIGHT
0% 100%
GRAMS STABLE
MOVE HIGHLIGHT MAIN MENU CONTRAST
QUICK CHECK
0% 100%
GRAMS STABLE
STOP MAIN CONTRAST NEW
DIFF = 0.00 REF WT = 300.44
DIFF % = 0.00
300.44
MAIN MENU
CHANGE UNITSPART S ET BALANCE
RETURN TO
WEIGH
CALIBRATION CUSTOM MENU
CHANGE MODE
CHANGE MODE
BASIC WEIGHING
PARTS COUNTING
FILLING
ANIMAL WEIGHING
CHECK WEIGHING
DIFF WEIGHING
FORMULATION
QUICK CHECK
STATISTICS
DENSITY
QUICK CHECK
0% 100%
GRAMS UNSTABLE
STOP MAIN CONTRAST NEW
DIFF = REF WT =
DIFF % =
WAIT FOR STABLE . . .
SET REFERENCE
PLEASE PUT THE REFERENCE WEIGHT
ON PAN AND PRESS < ENTER > . . .
