23
3.11 Formulation (Cont.)
Go Back
Help
Print Enter
FORMULA2 TARGET RESULT DIFF WT
B1 10.00 10.03 0.03
B2 20.00 20.08 0.08
B3 70.00 69.94 -0.06
TOTAL 100.00 100.05 0.05
• When all of the entries have been made, select SAVE
TO LIBRARY in the FORMULATION SETUP menu,
and then select RUN, press Enter button. The
balance displays the first component of the formula
and the required weight.
• Place a container on the pan and tare by pressing
>O/T< button.
• Add the required amount to the container until the
balance indicates 100% on the bar graph and the
proper percentage.
• Using the arrow buttons and select NEXT shown at
the bottom of the screen and press Enter button. The
second component of the formula is displayed. Add
the required weight. Select NEXT and repeat the
procedure for all items in the formula.
• When you have completed weighing all items in the
formula, select NEXT again and a display appears
which indicates the Target Weight, Result and Differ-
ence Weight for the formula. See display below.
Procedure
• Press arrow button and select WEIGH TYPE.
• Press Enter button, a new screen with WEIGHT and
PERCENT is displayed. PERCENT allows compon-
ents to be specified by percentage.
• Press or arrow button and select PER -
CENT.
• Press Enter button.
• Using arrow button, scroll to SET REFER-
ENCE.
• Press Enter button. A new screen, ENTER TARGET
WEIGHT appears.
• Using arrow buttons, enter target weight.
• Press Enter button, FORMULA SETUP is displayed.
• Using arrow button, scroll to NUMBER OF
ITEMS .
• Press Enter button. A new screen, SET ITEM
NUMBER appears.
• Press or arrow button and enter the num-
ber of components in the formula.
• Press Enter button, FORMULA SETUP is displayed.
• Press or arrow button and select SETUP.
• Press Enter button, NAME menu is displayed with the
number of items you entered for the first formula.
• Press or arrow button and select item 1.
• Press Enter button, COMPONENT NAME display
appears.
• Using arrow buttons, enter the component name for
item 1 in the formula.
• Press Enter button, a NAME menu appears with the
value shaded.
• Press Enter button, ENTER COMPONENT %
menu is displayed.
• Using the arrow buttons, enter the component per-
centage for item 1 in the formula.
• Press Enter button when desired weight is entered.
The NAME menu appears again. Repeat steps
and enter the component names and percent values
for the first formula.
FORMULATIONS BY PERCENTAGE
Formulations can be done by using percentages instead of weight values. See page 21 and repeat procedure up to
where screen choice for WEIGH TYPE is displayed, Then continue as follows:
