83
Appendix A - special applications
A-1 Sieve analysis
During most sieving operations, it is necessary to record the initial weight of each sieve before beginning as the
weights of the sieves may change due to particles being retained from the previous operation. In this procedure, the
basic sample is weighed first with its container weight tared. This sample weight is entered into the balance
manually and stored during the procedure. Then, each sieve is weighed in sequence and the weights are stored. After
the screening process, each sieve along with its retained sample, is weighed in sequence. The balance stores the
weight values and automatically subtracts the weight of each sieve and displays the retained amount in a table as
percent retension. Up to 80 sieve weights can be stored.
CHANGE MODE
Enter
From main menu
Enter CHANGE MODE and select DIFF WEIGHING, display advances to DIFF
WEIGHING SETUP with LIBRARY NAME highlighted.
DIFF WEIGHING
DIFF WEIGHING SETUP
LIBRARY NAME
Specify the library name
Specify the library name. The name can have any combination of alpha
numeric characters not to exceed 8 characters. After specifing the library
name, the display advances to DIFF STARTUP with SETUP highlighted. Press
the Enter button. The display advances to DIFF WEIGHING SETUP with TARE
SETUP highlighted.
DIFF4
Admissible ambient conditions
Use only in closed rooms
Temperature range:
10 ºC to 40 ºC/50º to 104º F with internal calibration
10 ºC to 30 ºC/50º to 86º F without internal calibration
Atmospheric humidity:
80% rh @ to 30 ºC
Voltage fluctuations:
15% +10%
Installation category:
II
Pollution degree:
2
Power supply voltage:
12 V ac, 50/60 Hz or 12 V dc, 1A
Power adapter:
AP2805E 220 - 240V, 50/60 Hz, 100 mA
AP2805 110 - 120V, 50/60 Hz, 150 mA
