40
Balance modes
DIFF WEIGHING SETUP Enter
Enter
Enter
LIBRARY NAME
TARE SETUP
AUTO SAMPLE OFF
DIFF RESULT WEIGHT
NUMBER OF SAMPLES
VIEW RESULTS
CLEAR ALL DATA
RUN
8.738
DIFF WEIGHING
PUT INITIAL CONTAINER #1 ON PAN STABLE
START/SAMPLE EDIT SETUP
CONTINUE SAVE RESAMPLE DELETE
23.076
DIFF WEIGHING
TARE WT: TARE WT:
IN IT WT: 23.076 FINAL WT:
PUT INITIAL SAMPLE #1 ON PAN STABLE
START/SAMPLE EDIT SETUP
CONTINUE SAVE RESAMPLE DELETE
TAREWT INIT WT TARE WT FINAL \VT
TAREWT INIT WT TARE WT FINAL \VT
8.738 0.000 N/A 0.000
8.738 O.O00 N/A 0.000
8.738 0.000 N/A 0.000
8.738 23.989 N/A 0.000
8.738 23.994 N/A 0.000
8.738 24.064 N/A 0.000
SAMPLE #1
8.738
DIFF WEIGHING
TARE WT: TARE WT:
IN IT WT: FINAL WT:8.738
PUT FINAL CONTAINER #1 ON PAN STABLE
START/SAMPLE EDIT SETUP
PRESS FOR MENU
SAMPLE # INIT WT FINAL WT WT DIFF
8.738 23.989 8.738 19.647
8.738 23.994 8.741 20.580
8.738 24.064 8.738 20.102
TARE WT INIT WT TARE WT FINAL \VT
CONTINUE SAVE RESAMPLE DELETE
SAMPLE #1
1 15.251 10.909 .342
2 15.256 1.839 -3.417
3 15.326 11.364 -3.962
TOTAL 45.833 34.112 -11.721
TARE WT: 8.738 TARE Wf:
IN IT WT: FINALWT:8.738
Dual Tare - Initial weighing (two containers)
This procedure is used when separate containers are used at the start of a
process and the end of a process. After pressing the Enter button, the
display indicates to PUT INITIAL CONTAINER #1 ON PAN.
Put container #1 on the pan. When the weight has stabilized, press Enter
button with START/SAMPLE highlighted on the display. This advances to the
next container. Continue adding containers and pressing the Enter button for
each container until all containers have been weighed. When the last
container has been weighed, the display indicates the initial weight of all
containers.
This sample display indicates 3 containers weighed. Four options are
available at the bottom of the display. CONTINUE permits continuing with the
procedure. SAVE permits saving the data and returns the balance to a
weighing mode. RESAMPLE allows going back to resample a selected entry.
DELETE permits deleting a selected entry.
Select CONTINUE. Display changes to PUT INITIAL SAMPLE #1 ON PAN.
Place sample # 1 on the pan, press Enter button. Repeat steps and
place each sample on the pan.
When the last sample is placed on the pan and entered, the display indicates
the tare weight of the containers and the initial weight of the samples.
Dual Tare - Final weighing (two containers)
After pressing the Enter button, the display returns to final weighing. Put final
container #1 on the pan. Repeat process for all containers.
Put first processed sample with the container on the pan. When the weight
has stabilized, press Enter button with START/SAMPLE highlighted on the
display. This advances to the next sample. Continue adding samples and
pressing the Enter button for each sample until all final samples have been
weighed. When the last sample has been weighed, the display indicates the
final weight of all samples. With CONTINUE highlighted, press Enter button
to review final display.
Final display.
