29
Weighing made simple
UNIT NAME
/ TO MOVE CURSOR
/ TO SCROLL CHARACTERS
PRESS TO ACCEPT
Unit name
Enter a unit name. The name you enter and custom unit characteristics will
be stored in the library when you complete all entries. Display returns to
CUSTOM UNIT SETUP with ENTER FACTOR highlighted.
UNIT1
CUSTOM UNIT SETUP
UNIT NAME UNIT1
ENTER FACTOR 1.0000
SELECT DP E-2
SELECT LSD LSD1
RETURN
Factor
Enter the factor number. This can be a number between 0.1 and 1.999999.
For conversion factors outside of this range, the exponent will be used to
move the decimal point.
CUSTOM UNIT SETUP
UNIT NAME UNIT1
ENTER FACTOR 1.0000
SELECT DP E-2
SELECT LSD LSD1
RETURN
Decimal point
Scroll to SELECT DP, press Enter button. SELECT DP LOCATION is displayed.
SELECT DP LOCATION
E-3
E-2
E-1
E0
E1
Select a decimal point. Scroll to either E-3, E-2, E-1, E0, E1, E2, or E3, and
press Enter button. Display returns to CUSTOM UNIT SETUP with UNIT NAME
highlighted.
CUSTOM UNIT SETUP
UNIT NAME UNIT1
ENTER FACTOR 1.0000
SELECT DP E-2
SELECT LSD LSD1
RETURN
Least significant digit
Scroll to SELECT LSD which is the Least Significant Digit, press Enter button.
SELECT LSD is displayed.
LSD’s
LSD 0.5 Adds one decimal place display counts by
5’s.
LSD 1 Display counts by 1’s.
LSD 2 Display counts by 2’s.
LSD 5 Display counts by 5’s.
LSD 10 Display counts by 10’s.
LSD 100 Display counts by 100’s.
RETURN TO SETUP
