38
Balance modes
Enter
TAREWT INIT WT TARE WT FINAL \VT
Enter
PRESS FOR MENU
N/A 7.705 NA 0.000
N/A 7.702 N/A 0.000
N/A 7.701 N/A 0.000
CONTINUE SAVE RESAMPLE DELETE
This sample display indicates 3 samples taken with no tare.
Four options are available at the bottom of the display. CONTINUE permits
continuing with the procedure. SAVE permits saving the data and returns the
balance to a weighing mode. RESAMPLE allows going back to resample a
selected entry. DELETE permits deleting a selected entry.
To return to your final weighing, find and select the Library name of your test.
The balance then returns to where you left off in your sampling procedure for
final weighing.
7.299
DIFF WEIGHING
TARE WT: TARE WT:
IN IT WT: FINAL WT:
PUT INITIAL SAMPLE #1 ON PAN STABLE
START/SAMPLE EDIT SETUP
No Tare - Final weighing
After pressing the Enter button, the display returns to final weighing. Put first
processed sample on the pan. When the weight has stabilized, press Enter
button with START/SAMPLE highlighted on the display. This advances to the
next sample. Continue adding samples and pressing the Enter button for
each sample until all final samples have been weighed. When the last
sample has been weighed, the display indicates the final weight of all
samples.
N/A 7.705 NA 7.299
N/A 7.702 N/A 7.299
N/A 7.701 N/A 7.299
CONTINUE SAVE RESAMPLE DELETE
TAREWT INITWT TARE WT FINAL \VT
With CONTINUE highlighted, press Enter button to review final display.
N/A 7.705 7.220 -0.407
N/A 7.702 7.299 -0.403
N/A 7.701 7.299 -0.402
TOTAL 23.109 21.896 -1.212
SAMPLE # INIT WT FINAL WT WT DIFF
Final display.
DIFF WEIGHING SETUP Enter
LIBRARY NAME
TARE SETUP
AUTO SAMPLE OFF
DIFF RESULT WEIGHT
NUMBER OF SAMPLES
VIEW RESULTS
CLEAR ALL DATA
RUN
0.000
DIFF WEIGHING
TARE WT: TARE WT:
IN IT WT: FINAL WT:
PUT INITIAL SAMPLE #1 ON PAN STABLE
START/SAMPLE EDIT SETUP
Single Tare - Initial weighing (one container)
This procedure is used when one container is used with the initial and final
samples. After pressing the Enter button, the display indicates PUT INITIAL
CONTAINER #1 ON PAN.
Put container #1 on the pan. When the weight has stabilized, press Enter
button with START/SAMPLE highlighted on the display. This advances to the
next container. Continue adding containers and pressing the Enter button for
each container until all containers have been weighed. When the last con-
tainer has been weighed, the display indicates the initial weight of all con-
tainers.
