Ohaus Voyager Balances - Manual (Page 33)

27
3.14 Density (Cont.)
3.14.2 Solid Density Determinations (Cont.)
As previously mentioned, the balance contains built in density tables for water and and ethanol. In the the event that
a different liquid is to be used, provisions are made to enter the density of the desired liquid and enter its name into a
library. The following procedure uses water as an example.
Go Back
Help
Print Enter
0.00
WEIGHT
0% 100%
GRAMS STABLE
MOVE HIGHLIGHT MAIN MENU CONTRAST
Procedure
• Press arrow button to select MAIN MENU.
• Press Enter button.
• Using the arrow buttons, select CHANGE MODE.
• Press Enter button.
• Press or arrow button and select DENSITY.
• Press Enter button.
• Press or arrow button and select SOLID.
• Press Enter button.
• Press or arrow button and select H2O.
NOTE: At this point you could also select either ethanol
or a different auxiliary liquid. When a different auxiliary
liquid is selected, you must enter its density and
name it for the library.
MAIN MENU
CHANGE UNITS SET BALANCE
LIBRARY CALIBRATION CUSTOM MENU
CHANGE MODE
MAIN MENU
CHANGE UNITS SET BALANCE
LIBRARY CALIBRATION CUSTOM MENU
CHANGE MODE
CHANGE MODE
BASIC WEIGHING
PARTS COUNTING
FILLING
ANIMAL WEIGHING
CHECK WEIGHING
DIFF WEIGHING
FORMULATION
QUICK CHECK
STATISTIC
DENSITY
• Install a 250ml beaker (not supplied) as shown when
using the density kit and suspend a precision cali-
brated thermometer 0° C to 30° C on the edge of the
beaker.
• Suspend the Weigh Below Hook from the Bracket into
the beaker.
• Fill the beaker with auxiliary liquid (liquid of known
density Q
0
' usually distilled water or ethanol). Insure
that the liquid will cover the sample by at least 1 cm
after immersion.
• Ensure that no air bubbles adhere to the immersed
part of the Weigh Below Hook. Remove air bubbles
by moving the Weigh Below Hook or by means of a
fine brush.
• Close the draft shield doors and tare the balance.
• Open the draft shield of the balance.
Beaker & Thermometer Installation
