52 Media
How to cut roll media
Introduction
The MAX 200 provides two roll cut methods, auto and manual.
Auto cut,
page 52. When the trim button is pressed, the machine
automatically cuts the roll media.
When a new roll is loaded into the drawer, use this
cut method to ensure a smooth cut.
Manual cut,
page 53. The operator uses the cutter knob to cut the media.
Use this method, when a media jam occurs and the
media jam length is very long. When the cutter knob
is used, media is cut at a slight angle.
Auto cut
Procedure
1. Press the offline button, on the printer control panel.
The printer is offline.
2. Press the trim button, on the RFC panel.
When the machine cuts the media, the trim indicator
lamp is lit.
The trimmed media is sent to the printer copy output
tray and the trim indicator lamp is off.
4. Remove the cut media, from the copy output tray.
5. Press the offline button.
The printer is online.
