260 Problem solving
Clearing a printer jam
When a printer jam occurs, an error message is displayed. Along
with the error message, use the printer diagram indicator lamps to
guide you to the printer area that needs attention.
If the jam occurs during the scanning process, the document image is
stored into memory and the jammed copies are remade, once the
jam is cleared.
Procedure
1. Document jam message is displayed.
2. The printer diagram indicates the media jam area.
3. Go to the appropriate media jam procedure.
•
For indicator lamps 1- 4, refer to page 261.
•
For indicator lamp 5, refer to page 262.
•
For indicator lamps 6 or 7, refer to page 263.
•
For indicator lamp 8, refer to page 264.
•
For indicator lamp 9, refer to page 266.
•
For indicator lamp 10, refer to page 268.
•
For indicator lamp 11 or 12, refer to page 270.
