206 How to customize the MAX 200
How to change the copy features (continued)
Folder setup (continued)
5. Select the desired fold program you want to setup.
Caution: You can set up P1, P2, or P3 to folds other than
P1= fan fold, P2 = cross fold, and P3 = special fold at the folder,
but the above screen displays P1= fan fold, P2 = cross fold, and
P3 = special fold. Ensue to power off and power on, the folder,
after changing any of the folds, other than what is displayed on
the above touch screen.
P1 Assigns the fold parameters to P1.
P2 Assigns the fold parameters to P2.
P3 Assigns the fold parameters to P3.
The fold program screen is displayed.
P1 P2 P3
Cancel Done Folder setup
Fan Fold
Standard
Add holes
30 mm
Cross Fold
Bigger
No holes
0 mm
Special Fold
Bigger
No holes
0mm
