Xerox MAX 200 - Manual (Page 283)

Technical data 281
Media specifications
Roll media Cut media Manual feed tray media
Media size ISO, E, D, C, B, A size
widths 8.5 x 11 inch to
12 x 18 inch, long edge
or short edge feed. ISO, E, D, C, B, A, size widths
Media weight 20 lb. 20 to 24 lb. 20 lb.
Media type Bond, vellum, film Bond Bond, vellum, film
System capability
Scanner resolution 15.7 dots/mm (400 dpi)
Warm-up time Max. 5 minutes (when breaker switch is held ON)
First copy output time 20 seconds for E
Lead edge registration Roll
±
3.0 mm
Cut sheet B
±
2 mm
Cut sheet A
±
0.5 mm
Side registration Maximum of
±
1.5 mm difference in multiple prints.
Skew Maximum of 1. 5 mm per 200 mm length
Lead edge deletion Roll media (outside diameter of 100 mm or greater) = 5 mm
Roll media (outside diameter of less than 100 mm) = 5 mm
Cut sheet = 5 mm
Trail edge deletion Roll media (outside diameter of 100 mm or greater) = 5 mm
Roll media (outside diameter of less than 100 mm) = 5 mm
Cut sheet = 5 mm
Image area size 880 mm wide
Continuous prints (per
minute) A: 29 minimum SEF, 36.5 minimum LEF
B: 22.2 minimum SEF, 29 minimum LEF
C: 16.9 minimum SEF, 22.2 minimum LEF
D: 12.5 minimum SEF, 16. 9 minimum LEF
E: 9.1 minimum SEF
Copy output tray
capacity (printer) 100 E-size sheets
Document exit tray
(scanner) 50 D-size sheets
50 E-size sheets with extension bar pulled out
Document size 36 inch maximum width
0.05 mm to 0.2 mm thickness
