SOLO LED Status Indicator
Located below the L/R meter display, the SOLO LED status indicator will
light and flash (red) when SOLO has been activated for any channel on the
mixer.
MEMORY Numeric Readout
The two-digit numeric readout displays the most recently accessed SCENE
MEMORY. Whenever an AUX monitoring selection button is activated for
either
MONITOR A or MONITOR B, the numeric display will momentarily
display the AUX selections.
CONSOLE LOCK LED Status Indicator
When illuminated (red), the password protection for an area or function of
the mixer is engaged, and selected mixer operations cannot be performed.
See Section 16-3, Utility, Configuration (CONFIG) Window for more
information.
C h a p t e r 2
D A 7 U s e r s ’ G u i d e 2 - 2 3
2
DA7 T
our
SOLO
SOLO LED Status Indicator
MEMORY Numeric Readout
CONSOLE
LOCK
CONSOLE LOCK LED Status Indicator
