MIDI Chart
Header
Header
Start of Exclusive
Structure of Multi Block Transfer (For Data Size over 256 bytes)
Start Block
Start of Exclusive
MIDI System Exclusive
Basic Structure of System Exclusive Message
Header
Header
’0’ - ’F’
XOR of Code from CMD to ETX
SOX F0H
IDC 54H Maker ID Code = Matsushita Communication Industrial Co., Ltd.
FMT 12H Format = One Way
MD 45H Model Name Code = WR-DA7
MDC 20H - 2FH [MIDI Channel] – 1 + 20H
P/S
50H/53H
ETX
BCC 03H
EOX F7H
’0’ - ’F’
’0’ - ’F’
Polling Message : 50H, Selecting Message : 53H
Command
End of Text
End of Exclusive
CMD
Footer
XOR of Code from CMD to ETB
SOX F0H
IDC 54H Maker ID Code = Matsushita Communication Industrial Co., Ltd.
FMT 12H Format = One Way
MD 45H Model Name Code = WR-DA7
MDC 20H - 2FH [MIDI Channel] – 1 + 20H
P/S
50H/53H
ETB
BCC 17H
EOX F7H
’0’ - ’F’
’0’ - ’F’
Polling Message : 50H, Selecting Message : 53H
Command
End of Text Block
End of Exclusive
CMD
Data
Footer
XOR of Code from Data to ETB
SOX F0H Start of Exclusive
IDC 54H Maker ID Code = Matsushita Communication Industrial Co., Ltd.
FMT 12H Format = One Way
MD 45H Model Name Code = WR-DA7
MDC 20H - 2FH [MIDI Channel] – 1 + 20H
P/S
50H/53H
ETB
BCC 17H
EOX F7H
’0’ - ’F’
Polling Message : 50H, Selecting Message : 53H
End of Text Block
End of Exclusive
Data
Footer
XOR of Code from Data to ETX
SOX F0H Start of Exclusive
IDC 54H Maker ID Code = Matsushita Communication Industrial Co., Ltd.
FMT 12H Format = One Way
MD 45H Model Name Code = WR-DA7
MDC 20H - 2FH [MIDI Channel] – 1 + 20H
P/S
50H/53H
ETX
BCC 03H
EOX F7H
’0’ - ’F’
’0’ - ’F’
Polling Message : 50H, Selecting Message : 53H
End of Text
End of Exclusive
Data
Footer
Middle Block
End Block
Data
