AUX5 PST (post-fader)
AUX6 PST (post-fader)
LEVEL AUX1 -
∞
AUX2 -
∞
AUX3 -
∞
AUX4 -
∞
AUX5 -
∞
AUX6 -
∞
PAN/BAL AUX1,2 C (center)
AUX3,4 C (center)
AUX5,6 C (center)
EQUALIZER ON/OFF OFF
LOW BAND FILTER PEQ
HIGH BAND FILTER PEQ
LOW Q PEQ 1
F PEQ 125Hz
HPF 125Hz
SHL 125Hz
G PEQ 0dB
HPF ON
SHL 0dB
L-MID Q 1
F 1KHz
G 0dB
H-MID Q 1
F 4KHz
G 0dB
HIGH Q PEQ 1
F PEQ 10KHz
LPF 10KHz
SHH 10KHz
G PEQ 0dB
LPF ON
SHH 0dB
DYNAMICS ON/OFF OFF
FUNCTION COMP+GATE
STEREO LINK OFF
POSITION POST EQ
COMP+GATE GATE THL OFF
ATT 10ms
RLS 100msec
COMP THL -20dB
RATIO 1:1
ATT 10msec
RLS 100msec
GAIN 0dB
EXP THL -20dB
RATIO 1:1
ATT 10msec
A p p e n d i x D
D A 7 U s e r s ’ G u i d e D - 2
D
Default Settings
