Selection Cursor

Pressing the

CURSOR MODE button displays the

in the lower right

corner of the LCD screen. In this

cursor mode, the

JogDial performs as

group selection that moves the cursor from group to group. The
disappears by pressing the

CURSOR MODE button again. Rotating the

JogDial moves the cursor from mark to mark in a selected group.

For grouping operations, switch the

JogDial to the cursor mode and scroll to

select the group. Then switch the

JogDial to the none-cursor mode and scroll

to select the marker in a group, and press the

ENTER button.

Registration Marks

The status of a channel is indicated in the columns of the tables in the
window:

shows a registered channel, and

shows an unregistered

channel.

A channel cannot be registered to multiple groups. When a channel is
assigned to a group, any previous assignment for it is cancelled automatically.

Creating a Fader Group

There are two methods for assigning a channel to a fader group while the
[FADER GRP] window is displayed.

Pressing a channel

SELECT LED button on the Top Panel to select the

channel (orange) will add the channel to the current fader group. If the
group selection marker is not positioned within the table which
includes the selected channel, the marker shifts to the relevant table
automatically. A registration mark will be displayed in the

[FADER GRP]

window table, denoting the channel selection for the respective group.

Pressing the

ENTER button in the cursor mode while the cursor is

positioned on the desired channel number will register the channel to
the current fader group. A registration mark will be displayed denoting
the channel selection for the current group.

C h a p t e r 1 3

D A 7 U s e r s ’ G u i d e

Group

Once the groups have been activated in the

[FADER GRP]

window, the window does not have to be displayed when you
want to register a group. Use the fader group selection buttons in
the

[CHANNEL] window to register the channel to a group.

■

To cancel all the channels assigned to a group, press one of the
SELECT buttons in the group for 2 seconds or more.
