Parameter button, Channel button, Assign selection] element – Panasonic WR-DA7 User Manual

Page 163: Clear all button, Setting of registration

Button

Select a parameter to be registered in the

[CONTROL CHANGE TABLE]

by rotating the

JogDial.

Button

Select a channel to be registered in the

[CONTROL CHANGE TABLE]

by rotating the

JogDial.

[Assign

] Element

This area indicates status. The parameter and channel are registered to
the selected table by pressing the

ENTER button. At that time, the

[Assign

] is highlighted and shows the selection. If a combination of

the selected parameter and channel is not acceptable, the arrow is
distorted, showing that the parameter and channel cannot be registered.

Button

Initialize the table. Cursor to the

button, and press the

ENTER button.

Setting of Registration

Press the

MIDI button on the Top Panel to display the [MIDI>CTRL

ASGN] window on the LCD.

Cursor to the

[CONTROL CHANGE TABLE] area. Turn the JogDial to

move the cursor to the line to be rewritten.

Press the up

ARROW button to move the cursor to [PARAMETER] in

the top part of the window. Rotate the

JogDial to display the desired

parameter.

Press the right

ARROW button to move the cursor to the field below

[CHANNEL] near the top of the window, and rotate the JogDial to
display the desired channel.

Press the

ENTER button. The [Assign

] element is shown inversely

for a moment. The selected item is written on the specified line.

C h a p t e r 1 1

D A 7 U s e r s ’ G u i d e

MIDI
