A-D/D-A Card (8 in / 8 out)
Input 1 ~ 8 (balanced)
Indicated impedance: 10k Ω
Nominal source impedance: 50 Ω ~ 600 Ω
Nominal input level: +4dB (1.23V)
Maximum input level
before clipping:
+18dB (6.15V)
Connector type: D-sub 25P
Output 1 ~ 8 (balanced)
Indicated impedance: 10k Ω
Nominal source impedance: 150
Ω
Nominal input level: +4dB (1.23V)
Maximum input level
before clipping:
+18dB (6.15V)
Connector type: D-sub 25P
SMPTE/V SYNC Card
SMPTE IN
in/out: In
Format: SMPTE (LTC)
Signal type: nominal -10dBV / 10k
Ω
Connector: XLR
V SYNC
in/out: In
Format: NTSC (B/W or color) / PAL
Signal type: 75
Ω
, termination
Connector: BNC
TANDEM Card (for running two DA7 mixers simultaneously)
Type: TANDEM connection
in/out: In and Out
Format: RAMSA SSA
Signal type: RS422
Connector: D-sub 25P
