C h a p t e r 1 1

D A 7 U s e r s ’ G u i d e

MIDI

[SCENE LIST TABLE] Area

Rotate the

JogDial to select a scene memory number.

[ASSIGN] Indicator

An arrow indicates a status. The scene memory is registered to the
selected table by pressing the

ENTER button. At that time, the

arrow symbol is highlighted and shows the selection.

Button

Initialize the table. Cursor to the

button, and press the

ENTER

button. This function returns all the data in the change table to the state of
default.

Setting of Registration

Press the

MIDI button in the SETUP section of the Top Panel to display

the

[MIDI>PRG ASGN] window on the LCD.

Cursor to the

[PROGRAM CHANGE TABLE] area. Rotate the JogDial to

move the cursor to the destination line.

Press the right

ARROW button, to cursor to the [SCENE LIST] area.

Rotate the

JogDial to cursor to the source line.

Press the

ENTER button. The [ASSIGN] indicator located between the

two tables is shown inversely for a moment. The selected line in the
[PROGRAM CHANGE TABLE] changes, for example, from 51=NO
ASSIGN to 51=0.8:SCENE NAME.

Refer to Appendix G, MIDI Implementation Chart for the control change
table and the control change parameter list.

Scene List Table
