D A 7 U s e r s ’ G u i d e

Equalizer

7-1 Overview

This chapter provides information on the

EQUALIZER section of the Top

Panel and the

[EQUALIZER] window group selections. A 4-band parametric

equalizer is available for each of the 32 channels, each of the 8 buses, and
MASTER L/R. A 2-band parametric equalizer is available for each of the six
aux returns. There are no parametric equalizers provided for the six aux
sends, which is not a problem because you can apply equalization to the
channel prior to assigning an aux send. Each equalizer band has controls for
Q factor, Frequency, and Gain.

The

[EQUALIZER] window provides filter type selections for refining the

specific equalization settings. In addition to the default filter type of

[PEQ]

(parametric equalizer) filtering, high pass, low pass, shelf high, and shelf low
filter types are available. The

[EQUALIZER] window also contains an [A/B]

function area which allows you to compare two equalizer settings for the
selected channel, and a

or “clear” function.

Chapter 7

Equalizer

EQUALIZER Section
