C h a p t e r 1 6

D A 7 U s e r s ’ G u i d e

1 3

Utility

16-4 Utility, User Custom (USER CSTM) Window

This window allows you to program which sources will be controlled by the
16 channels in the

CUSTOM/MIDI Fader Layer.

The

[FADER LAYER CUSTOMIZE ASSIGN TABLE] lets you assign sources

to the channels. The

[ASSIGN CH] (assign channel) selection can be any

source: inputs 1 through 32, aux returns 1 through 6, buses 1 through 8, and
aux sends 1 through 6. Cursor to the channel number that you want to
change, and rotate the

JogDial to select the desired source.

At the bottom of the channel assignment columns there is a
button. When selected, it changes to inverse video. When active, the columns
will change from [ASSIGN CH] information to [MIDI CH#]. Each of these
can be programmed to the desired MIDI channel selection and can be
assigned to MIDI message in the

[MIDI > MIDI RMT] window. When selected,

MIDI messages are reflected to

SOLO, ON, PAN and FADER functions of

respective channels in the

[MIDI > MIDI RMT] window.

Cursor to the

button, and press the

ENTER button to activate the

selections for use as the

CUSTOM/MIDI Fader Layer assignments.

For more information, see Chapter 11, MIDI.

USER CSTM Window
