Memory Maps
http://www.mcg.mot.com/literature
1-45
1
9. Eight bytes are reserved for the printed wiring board (PWB) number
assigned to the memory mezzanine board in ASCII format. This
does not include the
01-W
prefix. For example, for a 4MB
mezzanine at revision A, the PWB field contains:
3992B03A
10. Eight bytes are reserved for the serial number assigned to the
memory mezzanine board in ASCII format.
11. Eight bytes are reserved for the printed wiring board (PWB) number
assigned to the serial port 2 personality board in ASCII format.
Static Memory Mezzanine pwb identifier in ascii
Static Memory Mezzanine serial number in ascii
ECC1 Memory Mezzanine pwb identifier in ascii
ECC1 Memory Mezzanine serial number in ascii
ECC2 Memory Mezzanine pwb identifier in ascii
ECC2 Memory Mezzanine serial number in ascii
12. Eight bytes are reserved for the serial number assigned to the serial
port 2 personality board in ASCII format.
13. Eight bytes are reserved for the board identifier, in ASCII, assigned
to the optional first IndustryPack a.
14. Eight bytes are reserved for the serial number, in ASCII, assigned to
the optional first IndustryPack a.
15. Eight bytes are reserved for the printed wiring board (PWB) number
assigned to the optional first IndustryPack a.
16. Eight bytes are reserved for the board identifier, in ASCII, assigned
to the optional second IndustryPack b.
17. Eight bytes are reserved for the serial number, in ASCII, assigned to
the optional second IndustryPack b.
18. Eight bytes are reserved for the printed wiring board (PWB) number
assigned to the optional second IndustryPack b.
19. Eight bytes are reserved for the board identifier, in ASCII, assigned
to the optional third IndustryPack c.
