Programming Model

http://www.mcg.mot.com/literature

3-29

SRAM Space Size Register

SEN

SRAM ENABLE must be set to a one before the SRAM
can be accessed.

SZ1-SZ0

The size bits configure the SRAM decoder for a particular
memory size. The following table defines their use. Note
that the table specifies the allowed bit combinations for
SZ1 - SZ0. Any other combinations generate
unpredictable results.

SZ1 - SZ0 are set equal to the SZ1 - SZ0 bits of the
DRAM/SRAM Options Register. SZ1 - SZ0 are
programmable to facilitate diagnostic software.

Note

For an MVME172 with 128 KB of SRAM, the software must
program SZ1-SZ0 = $1 (512 KB). Therefore, the SRAM
contents will repeat in the memory map.

ADR/SIZ

$FFF42024 (8 bits)

BIT

NAME

SEN

SZ1

SZ0

OPER

RESET

0 PL

Table 3-7. SRAM Size Control Bit Encoding

SZ1 - SZ0

Memory Size

Reserved (do not use)

512 KB (or 128 KB)

1 MB

2 MB
