Memory Maps

http://www.mcg.mot.com/literature

1-15

1

$FFF58280 - $FFF582FF

IP2 IP_c ID

D16

128B

7

$FFF58300 - $FFF5837F

IP2 IP_d I/O

D16

128B

7

$FFF58380 - $FFF583FF

IP2 IP_d ID Read

D16

128B

7

$FFF58400 - $FFF584FF

IP2 IP_ab I/O

D32-D16

256B

1

$FFF58500 - $FFF585FF

IP2 IP_cd I/O

D32-D16

256B

7

$FFF58600 - $FFF586FF

IP2 IP_ab I/O Repeated

D32-D16

256B

1

$FFF58700 - $FFF587FF

IP2 IP_cd I/O Repeated

D32-D16

256B

7

$FFF58800 - $FFF5887F

Reserved

- -

128B

1

$FFF58880 - $FFF588FF

Reserved

- -

128B

1

$FFF58900 - $FFF5897F

Reserved

- -

128B

1

$FFF58980 - $FFF589FF

Reserved

- -

128B

1

$FFF58A00 - $FFF58A7F

Reserved

- -

128B

1

$FFF58A80 - $FFF58AFF

Reserved

- -

128B

1

$FFF58B00 - $FFF58B7F

Reserved

- -

128B

1

$FFF58B80 - $FFF58BFF

Reserved

- -

128B

1

$FFF58C00 - $FFF58CFF

Reserved

- -

256B

1

$FFF58D00 - $FFF58DFF

Reserved

- -

256B

1

$FFF58E00 - $FFF58EFF

Reserved

- -

256B

1

$FFF58F00 - $FFF58FFF

Reserved

- -

256B

1

$FFFBC000 - $FFFBC01F

IP2 Registers

D32-D8

2KB

1

Table 1-5. 200/300-Series MVME172 Local I/O Devices Memory Map

(Continued)

Address Range

Devices Accessed

Port

Width

Size

Notes
