Syndrome Decode
http://www.mcg.mot.com/literature
5-39
5
Syndrome Decode
A syndrome code value of $00 indicates no error found. All other
syndrome code values indicate an error with the bit in error decoded as
shown in the following table. Note that BANK A corresponds to A3,A2 =
00, BANK B to A3,A2 = 01, BANK C to A3,A2 = 10, and BANK D to
A3,A2 = 11.
Bank in Error
Bit in Error
Syndrome Code
BANK D
BIT 0/16
$8C
BANK D
BIT 1/17
$0D
BANK D
BIT 2/18
$0E
BANK D
BIT 3/19
$F4
BANK D
BIT 4/20
$15
BANK D
BIT 5/21
$16
BANK D
BIT 6/22
$26
BANK D
BIT 7/23
$25
BANK D
BIT 8/24
$19
BANK D
BIT 9/25
$1A
BANK D
BIT 10/26
$1C
BANK D
BIT 11/27
$E9
BANK D
BIT 12/28
$2A
BANK D
BIT 13/29
$2C
BANK D
BIT 14/30
$4C
BANK D
BIT 15/31
$4A
