1-41
1
Memory Maps
1Board Description and Memory Maps
0Memory Maps
Table 1-16. BBRAM Configuration Area Memory Map
Address Range
Description
Size (Bytes)
$FFFC1EF8 - $FFFC1EFB
Version
4
$FFFC1EFC - $FFFC1F07
Serial Number
12
$FFFC1F08 - $FFFC1F17
Board ID
16
$FFFC1F18 - $FFFC1F27
PWA
16
$FFFC1F28 - $FFFC1F2B
Speed
4
$FFFC1F2C - $FFFC1F31
Ethernet Address
6
$FFFC1F32 - $FFFC1F33
Reserved
2
$FFFC1F34 - $FFFC1F35
Local SCSI ID
2
$FFFC1F36 - $FFFC1F3D
Memory Mezz. PWB
8
$FFFC1F3E - $FFFC1F45
Memory Mezz. Serial Number
8
$FFFC1F46 - $FFFC1F4D
Static Mezz. PWB
8
$FFFC1F4E - $FFFC1F4D
Static Mezz. Serial
8
$FFFC1F56 - $FFFC1F5D
ECC1 Mezz. PWB
8
$FFFC1F5E - $FFFC1F5D
ECC1 Mezz Serial
8
$FFFC1F66 - $FFFC1F65
ECC2 Mezz. PWB
8
$FFFC1F6E - $FFFC1F75
ECC2 Mezz. Serial
8
$FFFC1F76 - $FFFC1F7D
Ser. Port 2 Pers. PWB
8
$FFFC1F7E - $FFFC1F85
Ser. Port 2 Pers. Serial No.
8
$FFFC1F86 - $FFFC1F8D
IP_a Board ID
8
$FFFC1F8E - $FFFC1F95
IP_a Board Serial Number
8
$FFFC1F96 - $FFFC1F9D
IP_a Board PWB
8
$FFFC1F9E - $FFFC1FA5
IP_b Board ID
8
$FFFC1FA6 - $FFFC1FAD
IP_b Board Serial Number
8
$FFFC1FAE - $FFFC1FB5
IP_b Board PWB
8
$FFFC1FB6 - $FFFC1FBD
IP_c Board ID
8
$FFFC1FBE - $FFFC1FC5
IP_c Board Serial Number
8
$FFFC1FC6 - $FFFC1FCD
IP_c Board PWB
8
4FFFC1FCE - $FFFC1FD5
IP_d Board ID
8
