LCSR Programming Model
http://www.mcg.mot.com/literature 2-93
2
Interrupt Level Register 3 (bits 16-23)
This register is used to define the level of the software 4 interrupt and the
software 5 interrupt.
SW4 LEVEL These bits define the level of the software 4 interrupt.
SW5 LEVEL These bits define the level of the software 5 interrupt.
Interrupt Level Register 3 (bits 8-15)
This register is used to define the level of the software 2 interrupt and the
software 3 interrupt.
SW2 LEVEL These bits define the level of the software 2 interrupt.
SW3 LEVEL These bits define the level of the software 3 interrupt.
ADR/SIZ $FFF40080 (8 bits [6 used] of 32)
BIT 23 22 21 20 19 18 17 16
NAME SW5 LEVEL SW4 LEVEL
OPER R/W R/W
RESET 0 PSL 0 PSL
ADR/SIZ $FFF40080 (8 bits [6 used] of 32)
BIT 15 14 13 12 11 10 9 8
NAME SW3 LEVEL SW2 LEVEL
OPER R/W R/W
RESET 0 PSL 0 PSL
