9 CHAPTER 2
Specifications
Profibus Services:
• DP Services
ID Number and GSD Support:
• 1003H with Standard GSD File (May
change if required)
Input Size:
• 0-122 Words
Output Size:
• 0-122 Words
Combined Input and Output Size:
• Not exceed 208 Words
ControlNet Option Board
Power Supply:
• +5V max - 350mA
Operating Temperature:
• 0 - 70° C (32° - 158° F)
ControlNet Baud Rate:
• 5 Mbit/second
Max I/O Data Capacity:
• Input - 250 bytes
• Output - 250 bytes
ControlNet Supported Features:
• Redundant Media
• Cyclic Messaging
RIO Option Board
Power Supply:
• +5V max - 350mA
Operating Temperature:
• 0 - 70° C (32° - 158° F)
RIO Baud Rate:
• 57.6, 115, 225 Kbit/second
Max I/O Data Capacity:
• Input - 63 bytes (Full Rack)
• Output - 63 bytes (Full Rack)
• 15 Bytes Discrete
• 48 Bytes Block
RIO Supported Features:
• Block Transfer Data
• IO Mode
• 1/4, 1/2, 3/4 and Full Rack
Control of the Rack_Size and Starting_Quarter Combi-
nations
EtherNet/IP™ Option Card
Power Supply:
• +5V max 450mA
Operating Temperature:
• 0 - 70° C (32° - 158° F)
Baud Rate:
• 10/100 Mbit/s
I/O Input:
• 2048 bytes
I/O Output:
• 2048 bytes
Application Interface:
• Parallel
Specification Rel. 2:
Starting Quarter Valid Rack Sizes
First For all Rack Sizes
Second For 1/4, 1/2, 3/4 Racks
Third For 1/4, 1/2 Racks
Fourth Only for 1/4 Racks
Table 1: Quarter Combinations
