56
5. Operation of CON Controllers
No. Operation Screen Remarks
7 Next, touch the target position
of position No. 1.
When the numerical keypad
appears, touch [1], [0] and then
touch [ENT].
To reenter the value, touch
[ESC].
8 When registering a new position
data, the default values set by
user parameters are
automatically entered for the
velocity, acceleration,
deceleration, etc.
In this example, the default
value is 100 mm/s.
9 Next, touch No. [001] of position
No. 1.
10 Touch the value for the
Increment.
When the numerical keypad
appears, touch [1] and then
touch [ENT].
11 Touch [Menu1].
12
