6. Operation of SEP
Controllers
[Pos Test]
The operating method is explained using an example of operation pattern 0.
Touch [Menu] to return to the test menu screen.
x Backward:
Touching [Backward] moves the actuator backward.
x Forward:
Touching [Forward] moves the actuator backward.
x Vel Override: The speed override changes to 10%, 50% and 100% every time [Vel Override] is
touched.
The current axis position is indicated.
The axis speed is indicated.
The electric current of the axis is indicated by
a percentage of the rating.
