7. Operation of MEC Controllers
No. Operation Screen Remarks
6 Touch the value field of position.
When the numeric keypad is
displayed, touch [5], [0], and then
[ENT]. Touch [Menu] to return to the
position setting screen
7 “50” is shown in the speed field. Touch [Menu] to return to the
position setting screen
8 Touch the value field of
acceleration.
When the numeric keypad is
displayed, touch [0], [.], [3], and
then [ENT]. Touch [Menu] to return to the
position setting screen
9 “0.30” is shown in the acceleration
field. Touch [Menu] to return to the
position setting screen
10 Touch the value field of
deceleration.
When the numeric keypad is
displayed, touch [0], [.], [3], and
then [ENT]. Touch [Menu] to return to the
position setting screen
11 “0.30” is shown in the deceleration
field. Touch [Menu] to return to the
position setting screen
