59
[Preparations]
Preparations
Alarm Clear
The motor stop condition (trip condition) is cleared by the protective function.
Start of alarm clear
Finish
Alarm is not cleared.
Clear the alarm by resetting power.
Alarm clear is finished.
Keeping pressing (about 5 seconds)
increases number of “ ” as shown left.
Reveal execution display
Keep pressing until the LED display of the console is changed to " ".
SET
S
SET
S
Do not disconnect the console cable from the servo driver during the proceeding from to
. If the connector is disconnected during the time by any chance, connect the connector
again, and restart the operation from the beginning.
by pressing and .
by pressing .
Enter the auxiliary function mode by
pressing once and four times in
the initial state of LED, and then bring in
M
MODE
Operation with Execution Display
Operations with Selection Display
After clearing the alarm, return to Selection Display referring to “Structure of Each Mode” (Page 48 and 49).
