Structure of each mode, Using the console – Panasonic MINAS E-series User Manual
Page 48
48
Using the Console
The structure of each mode and the mode switching procedure can be changed with each
button on the operation panel.
Initial state of console LED
Set button
SET
S
Mode switch
button
Selection Display
MODE
M
MODE
M
MODE
M
MODE
M
MODE
M
MODE
M
Monitor
Parameter
setting
EEPROM
writ
Normal-auto-
gain tuning
Copy function
Auxiliary
functions
Mode switch
button
Mode switch
button
Mode switch
button
Mode switch
button
Mode switch
button
Structure of Each Mode
