HOA Keypad Display Minor Fault Name
EF0
Option Card External Fault
An external fault condition is present.
Cause Possible Solution
An external fault was received from the
PLC with F6-03 set to 3, which allows the
drive to continue running after an external
fault occurs.
• Remove the cause of the external fault.
• Remove the external fault input from the PLC.
There is a problem with the PLC program. Check the PLC program and correct problems.
HOA Keypad Display Minor Fault Name
EF1
Pump Fault (Input Terminal S1)
External fault at multi-function input terminal S1.
EF2
Pump fault (input terminal S2)
External fault at multi-function input terminal S2.
EF3
Pump fault (input terminal S3)
External fault at multi-function input terminal S3.
EF4
Pump fault (input terminal S4)
External fault at multi-function input terminal S4.
EF5
Pump fault (input terminal S5)
External fault at multi-function input terminal S5.
EF6
Pump fault (input terminal S6)
External fault at multi-function input terminal S6.
EF7
Pump fault (input terminal S7)
External fault at multi-function input terminal S7.
EF8 Pump fault (input terminal S8)
External fault at multi-function input terminal S8.
Cause Possible Solutions
An external device has tripped an alarm
function.
Remove the cause of the external fault and reset the multi-function input value.
Wiring is incorrect.
• Ensure the signal lines have been connected properly to the terminals assigned for external fault detection
(H1-oo = 2C to 2F).
• Reconnect the signal line.
Multi-function contact inputs are set
incorrectly.
• Check if the unused terminals have been set for H1-oo = 2C to 2F (External Fault).
• Change the terminal settings.
HOA Keypad Display Minor Fault Name
EoF Emergency Override Forward Run
Cause Possible Solution
The multi-function digital input for
EmergOverrideFWD (H1-oo = AF) has
been closed.
Open H1-oo = AF if the emergency condition is no longer present
HOA Keypad Display Minor Fault Name
Eor Emergency Override Reverse Run
Cause Possible Solution
The multi-function digital input for
EmergOverrideREV (H1-oo = B0) has
been closed.
Open H1-oo = B0 if the emergency condition is no longer present
HOA Keypad Display Fault Name
E5
SI-T3 Watchdog Timer Error
The watchdog timed out.
Cause Possible Solution
Data has not been received from the PLC Execute DISCONNECT or ALM_CLR, then issue a CONNECT command or SYNC_SET command and
proceed to phase 3. Refer to the SI-T3 Option Technical Manual for more details on troubleshooting.
