YASNAC PC NC Operating Manual Chapter 3: HMI Process Operation
3 - 16
• Enter “5.” using the calculator’s keypad. “5.” is shown in the display. In the upper left corner
there is a small “4.”, and in the lower left corner there is a “+”.
• Select a grid cell in the Setup: Workshift screen. The border of the selected cell becomes a lack
line.
• Press the Put button on the calculator. “9.” is shown in the calculator display, and “9.000” is
entered into the grid cell, which has a yellow background because it is in edit mode.
• Press the + key on the numeric key pad. A “+” appears in the lower left corner of the display.
• Type “3.” using the calculator’s keypad. “3.” is shown in the calculator display. In the upper
left corner there is a small “9.”, and in the lower left corner there is a “+”.
• Press the Put button on the calculator. “12.” is shown in the calculator display, and “12.000”
is entered into the grid cell, which has a yellow background because it is still in edit mode.
Using the Fixed button:
• Display the calculator by pressing the Calc button .
• Press the expand button (>) to enlarge the calculator and show expanded functionality.
• Touch the pi key, which will show “3.141592653589793” in the calculator display.
• Touch the Fixed key to limit the number of digits shown after the decimal point. The display
now shows “3.1416”. Touch the Fixed key again to show more digits after the decimal.
• Touch the x^2 three times so that the display shows “9488.531016070572”.
• Hit the Fixed key again. The display now shows “9488.5310”.
The Help button invokes the context-sensitive help pointer. To use it, click on the help
button, then select the item for which help is desired. This will provide a short description
of the function of the item. The description also includes a Tell Me More button which
shows the corresponding section in the on-line manual.
If the Copy button is clicked while some text or a number is selected, that data is stored in
the windows system copy buffer. This works for all screens, even if the selected text is not
editable. However, the copy button is disabled if the current selection can not be copied.
Since it does not make sense to copy part of a number, when Copy is activated for a number the
entire number is copied, regardless of what is selected.
Clicking on the Paste button will cause the contents of the windows system copy buffer to
be placed in the selected area. Paste is disabled if the buffer is empty or the current selec-
tion can not be edited. Once an item is copied, it can be pasted multiple times.
Copying from a Program Display:
• Change to the Program:Editor screen.
• Touch inside the editor. This will enable the Paste button.
• Select some text in the editor. This will enable the Copy button.
