YASNAC PC NC Operating Manual APPENDIX 3: Parameter Tables
A3 - 71
1402 Minimum spindle revolution clamp for gear
3 r/min 0 30000
1403 Minimum spindle revolution clamp for gear
4 r/min 0 30000
1404 Maximum spindle revolution clamp for gear
1 r/min 0 30000
1405 Maximum spindle revolution clamp for gear
2 r/min 0 30000
1406 Maximum spindle revolution clamp for gear
3 r/min 0 30000
1407 Maximum spindle revolution clamp for gear
4 r/min 0 30000
1408 Spindle max motor speed for gear 1 r/min 0 30000
1409 Spindle max motor speed for gear 2 r/min 0 30000
1410 Spindle max motor speed for gear 3 r/min 0 30000
1411 Spindle max motor speed for gear 4 r/min 0 30000
1412 Spindle speed when spindle orientation
(SOR) ON r/min 0 32767
1413 Spindle speed when spindle gear shift (SRO)
ON r/min 0 32767
1414 Spindle indexing origin position 360/4096deg 0 4095
1415 Spindle, max speed corresponding to 10V r/min 0 32767
1416 Maximum spindle speed during solid tap r/min 0 32767
1417 Spindle position loop gain for solid tap 0.01[1/S] 0 32767
1418 Spindle C-axis, max speed corresponding to
10V r/min 0 666 Maximum spindle speed cor-
responding to 10 V of com-
mand (C-axis is used)
1419 Spindle gear A base speed r/min 0 32767
1435 Spindle, max speed corresponding to 10V
(Gear B) r/min 0 32767
1436 Maximum spindle speed during solid tap
(Gear B) r/min 0 32767
1437 Spindle position loop gain for solid tap (Gear
B) 0.01[1/S] 0 32767
1439 Spindle gear B base speed r/min 0 32767
1500 Solid tap servo shaft retraction in-position
width 0.001mm 0 32767
1502 Solid tap synchronization offset parameter
K1 -32767 32767
1503 Solid tap synchronization offset parameter
K2 -32767 32767
1506 Rotary tool spindle sync offset parameter K1 -32767 32676
1507 Rotary tool spindle sync offset parameter K2 -32767 32676
Address Bit Description
Register
Units
Minimum
Value
Maximum
Value
Long Description
