YASNAC PC NC Operating Manual APPENDIX 3: Parameter Tables
A3 - 54
I/O
Address Bit Description
Register
Units
Minimum
Value
Maximum
Value
Long Description
pm905 Calendar output function, date setting No.1
pm906 Calendar output function, date setting No.2
pm907 Calendar output function, date setting No.3
pm908 Calendar output function, date setting No.4
pm1000 1 Spindle output when AFL signal is ON
1: S command is not accepted
0: Output Spindle DA is accepted
0 1
5 SSTP enable setting
1: SSTP enable when signal is 1
0: SSTP enable when signal is 0
0 1 SSTP setting for “0” output in
response to “0” S command
pm1001 0 Output sign of S in S5-digit command
0: M03 + / M04 +
1: M03 - / M04 -
2: M03 + / M04 -
3: M03 - / M04 +
0 3
pm1003 2 D/A output status is input to the PLC
0: Yes
1: No
0 1
pm2000 4 Validity of feedrate override signal
0: Valid when “1” (A contact)
1: Valid when “0” (B contact)
0 1
pm2400 JOG feedrate corresponding switch position
0 mm/min 0 32767
pm2401 JOG feedrate corresponding switch position
1 mm/min 0 32767
pm2402 JOG feedrate corresponding switch position
2 mm/min 0 32767
pm2403 JOG feedrate corresponding switch position
3 mm/min 0 32767
pm2404 JOG feedrate corresponding switch position
4 mm/min 0 32767
pm2405 JOG feedrate corresponding switch position
5 mm/min 0 32767
pm2406 JOG feedrate corresponding switch position
6 mm/min 0 32767
pm2407 JOG feedrate corresponding switch position
7 mm/min 0 32767
pm2408 JOG feedrate corresponding switch position
8 mm/min 0 32767
pm2409 JOG feedrate corresponding switch position
9 mm/min 0 32767
pm2410 JOG feedrate corresponding switch position
10 mm/min 0 32767
