YASNAC PC NC Operating Manual APPENDIX 3: Parameter Tables
A3 - 89
6823 3rd axis, third reference point position 0.001mm -999999999 999999999
6824 4th axis, third reference point position 0.001mm -999999999 999999999
6825 5th axis, third reference point position 0.001mm -999999999 999999999
6831 1st axis, fourth reference point position 0.001mm -999999999 999999999
6832 2nd axis, fourth reference point position 0.001mm -999999999 999999999
6833 3rd axis, fourth reference point position 0.001mm -999999999 999999999
6834 4th axis, fourth reference point position 0.001mm -999999999 999999999
6835 5th axis, fourth reference point position 0.001mm -999999999 999999999
6861 1st axis, pitch error compensation stroke
(maximum) 0.001mm -999999999 999999999
6862 2nd axis, pitch error compensation stroke
(maximum) 0.001mm -999999999 999999999
6863 3rd axis, pitch error compensation stroke
(maximum) 0.001mm -999999999 999999999
6864 4th axis, pitch error compensation stroke
(maximum) 0.001mm -999999999 999999999
6865 5th axis, pitch error compensation stroke
(maximum) 0.001mm -999999999 999999999
6871 1st axis, pitch error compensation stroke
(minimum) 0.001mm -999999999 999999999
6872 2nd axis, pitch error compensation stroke
(minimum) 0.001mm -999999999 999999999
6873 3rd axis, pitch error compensation stroke
(minimum)
0.001mm -999999999 999999999
6874 4th axis, pitch error compensation stroke
(minimum) 0.001mm -999999999 999999999
6875 5th axis, pitch error compensation stroke
(minimum) 0.001mm -999999999 999999999
6881 1st axis, pitch error comp reference point
position 0.001mm -999999999 999999999
6882 2nd axis, pitch error comp reference point
position 0.001mm -999999999 999999999
6883 3rd axis, pitch error comp reference point
position 0.001mm -999999999 999999999
6884 4th axis, pitch error comp reference point
position 0.001mm -999999999 999999999
6885 5th axis, pitch error comp reference point
position 0.001mm -999999999 999999999
6901 No.1 stored stroke limit 1st axis (+) 0.001mm -999999999 999999999
6902 No.1 stored stroke limit 2nd axis (+) 0.001mm -999999999 999999999
6903 No.1 stored stroke limit 3rd axis (+) 0.001mm -999999999 999999999
6904 No.1 stored stroke limit 4th axis (+) 0.001mm -999999999 999999999
6905 No.1 stored stroke limit 5th axis (+) 0.001mm -999999999 999999999
Address Bit Description
Register
Units
Minimum
Value
Maximum
Value
Long Description
