YASNAC PC NC Operating Manual APPENDIX 3: Parameter Tables
A3 - 64
929 Manual skip position data, No.4 point 1st
axis 0.001mm -99999999 99999999 Manual skip position informa-
tion, No.4 point (X-Z).
930 Manual skip position data, No.4 point 2nd
axis 0.001mm -99999999 99999999 Manual skip position informa-
tion, No.4 point (X-Z).
931 Manual skip position data, No.4 point 3rd
axis 0.001mm -99999999 99999999 Manual skip position informa-
tion, No.4 point (X-Z).
932 Manual skip position data, No.5 point 1st
axis 0.001mm -99999999 99999999 Manual skip position informa-
tion, No.5 point (X-Z).
933 Manual skip position data, No.5 point 2nd
axis 0.001mm -99999999 99999999 Manual skip position informa-
tion, No.5 point (X-Z).
934 Manual skip position data, No.5 point 3rd
axis 0.001mm -99999999 99999999 Manual skip position informa-
tion, No.5 point (X-Z).
935 Manual skip position data, No.6 point 1st
axis 0.001mm -99999999 99999999 Manual skip position informa-
tion, No.6 point (X-Z).
936 Manual skip position data, No.6 point 2nd
axis 0.001mm -99999999 99999999 Manual skip position informa-
tion, No.6 point (X-Z).
937 Manual skip position data, No.6 point 3rd
axis 0.001mm -99999999 99999999 Manual skip position informa-
tion, No.6 point (X-Z).
1000 1 Spindle output when AFL signal is ON 0 1
2 Override setting on spindle speed output 0 1
4 Filter for spindle load and speed 0 1 Filtering in the I/O out put for
the spindle load and speed
monitor
5 SSTP enable setting 0 1 SSTP setting for “0” output in
response to “0” S command
7 SAGR check when rapid to feed 0 1 Checking of SAGR when feed
rate is changed from rapid to
feed
1001 0 Output sign of S in S5-digit command 0 3
1002 0 Magnification ratio of spindle speed 0 1
1003 2 D/A output status is input to the PLC 0 1
1020 0 1st axis YENET station number 0 15 1st Physical servo axis
YENET1200 station number
setting (No. 2 to No. 15 sta-
tion)
5 1st axis debug mode 0 1
6 1st axis Physical servo axis specifications 0 1
7 1st axis Physical servo axis enable 0 1
1021 0 2nd axis YENET station number 0 15 2nd Physical servo axis
YENET1200 station number
setting (No. 2 to No. 15 sta-
tion)
5 2nd axis debug mode 0 1
6 2nd axis Physical servo axis specifications 0 1
7 2nd axis Physical servo axis enable 0 1
Address Bit Description
Register
Units
Minimum
Value
Maximum
Value
Long Description
