YASNAC PC NC Operating Manual
APPENDIX 3: Parameter Tables
A3 - 62
Machine Setup
Address
Bit
Description
Register
Units
Minimum
Value
Maximum
Value
Long Description
7
2
Occurrence of alarm if no skip signal in skip
block
0
1
Occurrence of an alarm if skip
signal is not turned ON until
the completion of axis move
specified in the skip function
block.
8
0
No. 2 stored stroke limit
0
1
1
No. 3 stored stroke limit
0
1
2
No. 4 stored stroke limit
0
1
3
No. 5 stored stroke limit
0
1
4
No. 2 entry prohibited area
0
1
5
No. 3 entry prohibited area
0
1
6
No. 4 entry prohibited area
0
1
7
No. 5 entry prohibited area
0
1
420
Manual skip contact direction monitor No.1
Bit information D1: X+
D2:Y+ D3:Z+ D8:X- D9:Y-
D10:Z-
421
Manual skip contact direction monitor No.2
Bit information D1: X+
D2:Y+ D3:Z+ D8:X- D9:Y-
D10:Z-
422
Manual skip contact direction monitor No.3
Bit information D1: X+
D2:Y+ D3:Z+ D8:X- D9:Y-
D10:Z-
423
Manual skip contact direction monitor No.4
Bit information D1: X+
D2:Y+ D3:Z+ D8:X- D9:Y-
D10:Z-
424
Manual skip contact direction monitor No.5
Bit information D1: X+
D2:Y+ D3:Z+ D8:X- D9:Y-
D10:Z-
831
No.2 stored stroke limit 1st axis (+)
0.001mm
-999999999
999999999
832
No.2 stored stroke limit 2nd axis (+)
0.001mm
-999999999
999999999
833
No.2 stored stroke limit 3rd axis (+)
0.001mm
-999999999
999999999
834
No.2 stored stroke limit 1st axis (-)
0.001mm
-999999999
999999999
835
No.2 stored stroke limit 2nd axis (-)
0.001mm
-999999999
999999999
837
No.3 stored stroke limit 1st axis (+)
0.001mm
-999999999
999999999
838
No.3 stored stroke limit 2nd axis (+)
0.001mm
-999999999
999999999
839
No.3 stored stroke limit 3rd axis (+)
0.001mm
-999999999
999999999
840
No.3 stored stroke limit 1st axis (-)
0.001mm
-999999999
999999999
841
No.3 stored stroke limit 2nd axis (-)
0.001mm
-999999999
999999999
842
No.3 stored stroke limit 3rd axis (-)
0.001mm
-999999999
999999999
843
No.4 stored stroke limit 1st axis (+)
0.001mm
-999999999
999999999
844
No.4 stored stroke limit 2nd axis (+)
0.001mm
-999999999
999999999
