YASNAC PC NC Operating Manual
APPENDIX 3: Parameter Tables
A3 - 70
1201
4th axis address name during high speed
mode
ascii
0
255
1202
5th axis address name during high speed
mode
ascii
0
255
1220
Spindle index confirmation timer
8msec
1
255
1225
Spindle index stopped confirmation revolu-
tions
r/min
1
255
1226
Spindle index stopped confirmation revolu-
tions B
r/min
1
255
Spindle index stopped confir-
mation revolutions at selec-
tion of spindle gear B-axis
1240
Spindle number for executing solid tap
0
1
1241
Servo axis number for executing solid tap
1
5
1252
Return feedrate multiplication for solid tap
0.1times
1
255
1260
Spindle loop control gear number (A)
0
4
1261
Spindle loop control gear number (B)
0
4
1321
1st axis Error detect-On area
0.001mm
0
255
1322
2nd axis Error detect-On area
0.001mm
0
255
1323
3rd axis Error detect-On area
0.001mm
0
255
1324
4th axis Error detect-On area
0.001mm
0
255
1325
5th axis Error detect-On area
0.001mm
0
255
1331
Error detect-ON area during spindle loop
control
0.001mm
0
255
1332
Error detect-ON area during spindle loop
control B
0.001mm
0
255
1351
Servo error range when spindle loop control
%
0
255
Spindle, Multiplication rela-
tive to rapid feed in servo error
range
1352
Servo error range when spindle loop control
%
0
255
Spindle, Multiplication rela-
tive to rapid feed in servo error
range for gear B
1371
1st axis Reduced vibration level when servo
stop
%
0
100
1372
2nd axis Reduced vibration level when servo
stop
%
0
100
1373
3rd axis Reduced vibration level when servo
stop
%
0
100
1374
4th axis Reduced vibration level when servo
stop
%
0
100
1375
5th axis Reduced vibration level when servo
stop
%
0
100
1400
Minimum spindle revolution clamp for gear
1
r/min
0
30000
1401
Minimum spindle revolution clamp for gear
2
r/min
0
30000
Address
Bit
Description
Register
Units
Minimum
Value
Maximum
Value
Long Description
