YASNAC PC NC Operating Manual APPENDIX 3: Parameter Tables
A3 - 72
1510 No. of teeth of gear A on the spindle side tooth 0 32767 No. of teeth of gear A on the
spindle side for spindle loop
control
1511 No. of teeth of gear A on the spindle tooth 0 32767 No. of teeth of the spindle
intermediate gear A used for
spindle loop control
1512 No. of teeth of gear A on the motor interme-
diate tooth 0 32767 No. of teeth of the motor inter-
mediate gear A used for spin-
dle loop control.
If there is no intermediate
gear, set 0
1513 No. of teeth of gear A on the motor side
intermediate tooth 0 32767 No. of teeth on the motor side
of gear A used for spindle loop
control.
If there is no intermediate
gear, set 0
1514 No. of teeth of gear B on the spindle side
intermediate tooth 0 32767 No. of teeth of gear B on the
spindle side for spindle loop
control.
If there is no intermediate
gear, set motor side one
1515 No. of teeth of gear B on the spindle interme-
diate tooth 0 32767 No. of teeth of the spindle
intermediate gear B used for
spindle loop control.
If there is no intermediate
gear, set 0
1516 No. of teeth of gear B on the motor interme-
diate tooth 0 32767 No. of teeth of the motor inter-
mediate gear B used for spin-
dle loop control.
If there is no intermediate
gear, set 0
1517 No. of teeth of gear B on the motor side tooth 0 32767 No. of teeth on the motor side
of gear B used for spindle loop
control
1540 Delay time to check the SAGR signal msec 0 32767 If there is no intermediate
gear, set 0
1551 1st axis backlash compensation amount 0.1micron 0 32767
1552 2nd axis backlash compensation amount 0.1micron 0 32767
1553 3rd axis backlash compensation amount 0.1micron 0 32767
1554 4th axis backlash compensation amount 0.1micron 0 32767
1555 5th axis backlash compensation amount 0.1micron 0 32767
1561 1st axis No of teeth of monitor when servo
feed change tooth 1 255
1562 2nd axis No of teeth of monitor when servo
feed change tooth 0 255
1563 3rd axis No of teeth of monitor when servo
feed change tooth 0 255
1564 4th axis No of teeth of monitor when servo
feed change tooth 0 255
Address Bit Description
Register
Units
Minimum
Value
Maximum
Value
Long Description
