YASNAC PC NC Operating Manual Chapter 3: HMI Process Operation
3 - 66
3.7.2 PC Settings Screen
Fig. 3.7.2.1 The PC Settings Screen
The Utilities: PC Settings screen, shown in Figure 3.7.2.1 on page 66, provides easy access to
common system tasks such as setting keyboard and mouse configurations or calibrating the touch
screen. Many of these functions are not available at certain user levels; the required access level
for each is shown in Table 3.7.2.1 on page 66.
Table 3.7.2.1 User Levels Required for PC Settings Functions
Icon Name Function Minimum Required User
Level
Accessibility
Used to customize software to
work more easily for people with
physical limitations.
Machinist
Console Window
Opens a DOS window where
commands may be entered.
MTB
Date & Time
Allows the computer’s date, time
and time zone settings.
Operator
Disk Administrator
The Disk Administrator can be
used to manage the hard disk,
such as partitioning new disks or
further partitioning disks.
MTB
