YASNAC PC NC Operating Manual APPENDIX 3: Parameter Tables
A3 - 16
5403 Time from ESP signal rising to base block on
3rd axis msec 0 32767 multiply of 10msec
6000 2 Pitch error compensation 3rd axis 0 1
6002 2 No.1 stored stroke limit check 3rd axis exe-
cution 0 1
6004 2 Execution of stored stroke limit check for
rotary 3rd axis 0 1
6006 2 Axis disconnection 3rd axis 0 1
6103 3rd axis, pitch error compensation 0 3
6403 3rd axis, pitch error start memory number 0 1151
6413 3rd axis, pitch error completion memory
number 0 1151
6423 3rd axis, pitch error reference point memory
number 0 1151
6803 3rd axis, pitch error compensation intervals 0.001mm 0 999999999
6813 3rd axis, second reference point position 0.001mm -999999999 999999999
6823 3rd axis, third reference point position 0.001mm -999999999 999999999
6833 3rd axis, fourth reference point position 0.001mm -999999999 999999999
6863 3rd axis, pitch error compensation stroke
(maximum) 0.001mm -999999999 999999999
6873 3rd axis, pitch error compensation stroke 0.001mm -999999999 999999999
6883 3rd axis, pitch error comp reference point
position 0.001mm -999999999 999999999
6903 No.1 stored stroke limit 3rd axis (+) 0.001mm -999999999 999999999
6913 No.1 stored stroke limit 3rd axis (-) 0.001mm -999999999 999999999
8000 2 Absolute motor zero return condition 3rd
axis 0 1
8001 2 Absolute motor position gap condition 3rd
axis 0 1
8403 3rd axis, fine adjust amount in zero point -32767 32767
8413 3rd axis, position gap distance limit when
power ON 0 32767
8473 3rd axis (- to +) roundness irregularity Inte-
gral constant msec 0 32767
8483 3rd axis (- to +) roundness irregularity com-
pletion torque 0.01% 0 20000
8493 3rd axis roundness irregularity Timing
parameter 0.01[1/S] -32767 32767
8523 3rd axis roundness irregularity weight com-
pensation torque 0.01% -12000 12000
8803 3rd axis, power OFF machine position 0.001mm -999999999 999999999
8813 3rd axis, offset amount in zero point setting pulse -999999999 999999999
Address Bit Description
Register
Units
Minimum
Value
Maximum
Value
Long Description
