YASNAC PC NC Operating Manual APPENDIX 3: Parameter Tables
A3 - 25
2465 5th axis rapid feed accel/decel time constant msec 4 32767 Set multiple of 4
2485 5th axis backlash compensation amount in
G01 mode 0.1micron -32767 32767
2495 5th axis backlash compensation amount in
Handle 0.1micron -32767 32767
2505 5th axis accel/decel time constant in feed cut msec 0 32767
2515 5th axis accel/decel time constant in thread/
tap msec 0 32767
2525 5th axis reference point return approach
speed mm/min,
deg/min
0 32767
2535 5th axis reference point return creep speed mm/min,
deg/min
0 32767
2565 5th axis accel/decel time constant in handle
feed msec 0 32767 Set multiple of 4
2575 5th axis accel/decel time constant in No2
G00 mode msec 0 32767 Set multiple of 4
2595 5th axis rapid feed accel/decel S-curve 0 20
2605 5th axis rapid feed accel/decel S-curve in
2nd S 0 15
2805 5th axis Rapid feed rate mm/min 0 240000
2815 5th axis rapid feed rate in 2nd S-curve mm/min,
deg/min
0 240000
2825 5th axis bias in normal cutting accel/decel mm/min,
deg/min
0 240000
2835 5th axis bias in thread cutting accel/decel mm/min,
deg/min
0 240000
2855 5th axis second G00 feedrate mm/min,
deg/min
0 240000
4002 4 5th axis Reference point return direction 0 1
4004 4 Alarm occur if axis move command before
ZRN 5th axis 0 1 Occurrence of alarm if move-
ment command other than G28
is executed without carrying
out manual or automatic refer-
ence point return for 5th axis
4006 4 5th axis Automatic coordinate system setting 0 1
4014 4 5th axis Direction of G60 unidirectional
positioning 0 1
4022 4 5th axis validity of reference point return 0 1
4024 4 5th axis validity of playback write 0 1
4455 5th axis reference point return traverse dis-
tance 0.001mm 0 32767
4465 5th axis overtravel distance in G60 0.001mm 0 32767
4555 Virtual C-phase shift distance 5th axis 0.001mm -32767 32767
Address Bit Description
Register
Units
Minimum
Value
Maximum
Value
Long Description
