YASNAC PC NC Operating Manual
APPENDIX 3: Parameter Tables
A3 - 42
Canned Cycle
Address
Bit
Description
Register
Units
Minimum
Value
Maximum
Value
Long Description
pm400
Dwell period for G76, G77
msec
0
32767
pm401
Pitch dwell period for G73, G83
msec
0
32767
pm805
Angle when G76, G77 are specified
0.001deg
0
360000
pm870
Return amount of G73
0.001mm
0
999999999
Return stroke in G73 cycle
(rapid traverse)
pm871
Return amount of G83
0.001mm
0
999999999
Return stroke in G83 cycle
(rapid traverse)
pm873
Return amount of G184/G174
0.001mm
0
999999999
Return stroke in G184/G174
cycle (rapid traverse)
pm2864
Shift speed of canned cycle G76 and G77
mm/min
0
240000
pm4016
1
Positioning mode in a canned cycle
0:
G00
1:
G00 or G01 which ever is present
0
1
2
M code to be output in the G74/G84 canned
cycle
0:
M code reverse one specified before
start
1:
M03 for G74 and M04 for G84
0
1
3
Output M05 at hole bottom in G74/G84
cycle
0:
No
1:
Yes
0
1
4
Execution type of G184/G174
1:
Pecking cycle (type B)
0:
Return to R-point
0
1
6
Solid tap in Dry run mode
0:
Normal tap
1:
Solid tap
0
1
pm4017
1
Output of M05 before the output of M19 in
the
0:
No
1:
Yes
0
1
2
Spindle over-ride during the execution of
G84/G74 tap cycle
0:
Fixed at 100%
1:
Fixed at the value read at the start
0
1
3
Validity of pm0400 dwell time in the G76/
G77 cycle
1:
Valid
0:
Invalid
0
1
4
Validity of pm0401 pitch dwell time
1:
Valid
0: nvalid
0
1
