YASNAC PC NC Operating Manual APPENDIX 3: Parameter Tables
A3 - 100
NC System
Address Bit Description
Register
Units
Minimum
Value
Maximum
Value
Long Description
0 0 Single-block switch 0 1
1 Machine lock switch 0 1
2 Dry run switch 0 1
3 Block delete switch 0 1
4 Manual absolute switch 0 1
5 Auxiliary function lock switch 0 1
6 Display lock switch 0 1
7 Edit Lock switch 0 1
1 0 Optional stop switch 0 1
1 Start lock switch 0 1
2 Z-axis neglect switch 0 1
2 0 Mirror image 1 0 1
1 Mirror image 2 0 1
2 Mirror image 3 0 1
3 Mirror image 4 0 1
4 Mirror image 5 0 1
3 1 Axis disconnection designation (4th-axis) 0 1
2 Axis disconnection designation (5th-axis) 0 1
5 0 Manual zero return switch 0 1
1 No. 2 manual zero return switch 0 1
2 Interruption point return switch 0 1
3 Automatic mode handle offset switch 0 1
4 Setup point return switch 0 1
5 Playback switch 0 1
6 F1-digit switch 0 1
7 Program restart switch 0 1
7 6 “0” data in parameter output 0 1
48 0 Servo current adjustment 0 1 Servo U-phase V-phase cur-
rent command offset adjust-
ment
107 Manual skip measuring point monitor 0 6
109 Internal system number switch setting 0 1
811 1st axis skip position 0.001mm -999999999 999999999 Coordinate values when skip
signal is operating (1st axis)
812 2nd axis skip position 0.001mm -999999999 999999999 Coordinate values when skip
signal is operating (2nd axis)
