Yaskawa Yasnac PC NC User Manual
Page 102
YASNAC PC NC Operating Manual
Chapter 3: HMI Process Operation
3 - 50
•
Press the Return key to place the moved text on a line of its own.
The Run This button is similar in behavior to the Run This button on the Program: File
screen. Clicking on this will set the program under edit to be the current program, and any
unsaved modifications to the program will be saved automatically. The Run: Production
screen will then be shown. A warning dialog will be shown if this is clicked when the selected file
is on a removable or network drive. This button is disabled if the system is not in MEM mode.
The Close button removes the current file from the drop-down menu of files that can be
edited. Additionally, the file will no longer appear in the Program: List screen.
Copy This is used to make a copy of the contents of the current buffer, if enough disk
space is available. This will display the directory selection popup, shown in Figure 3.4.2.3
on page 50. The interface is a standard file browser, discussed in “File Browser” on
There are several parameters that control whether macro programs (programs in the 8000 and
9000 ranges) can be displayed or edited. These parameters are listed in Table 8. The effects of
combining these parameters are outlined in Table 9 and Table 10.
Fig. 3.4.2.3
Save As Dialog
The Save button can be used to save changes to the program. For the most part, this is
unneccessary because files are always saved when leaving this screen. If a file is not
saved when the system is shut down, a dialog will prompt the user to save the file.
