Model 5700 Installation and Operation Manual 151295
6-21
Point
(cont.)
Internal and External
Power Supply Point #
B SWITCH STATUS PT
Zone # (*001) Used to activate an
ancillary Output
Group that does
not activate alarm,
sound PZT,
display status or
report events.
Reset has no affect
on this point.
Section 7.5.2
Point Name
A SWITCH Same as B SWITCH
Section 7.5.2
B DETECT
2WIRE SMK,
4WIRE SMK,
CO 4WIRE
*Silenceable (SI) or
Non-Silenceable
(NS)
Zone # (*001)
Point Name
A DETECT
2WIRE SMK,
4WIRE SMK,
CO 4WIRE
*Silenceable (SI) or
Non-Silenceable
(NS)
Zone # (*001)
Point Name
5880 Point #
UNUSED
Section 7.5.3
NOTIF
NOTIF OUT,
CTRL CKT Group # (*001)
Point Name
SWITCH
MAN _PULL,
PAS_ACK, MAN
REL, ILOCK
*Silenceable (SI) or
Non-Silenceable
(NS)
Zone # (*001)
Point Name
WATERFLOW,
SUPERVSY,
ZN_AUX1,
ZN_AUX2,
TAMPER
Zone (*001)
*Latching (LA) or
Non-Latching (NL)
*Silenceable (SI) or
Non-Silenceable
(NS)
Point Name
FIREDRILL,
SILENCE, RESET
*Silenceable (SI) or
Non-Silenceable
(NS)
Point Name
SYS_AUX1,
SUS_AUX2
*Latching (LA) or
Non-Latching (NL)
*Silenceable (SI) or
Non-Silenceable
(NS)
STATUS PT
Zone # (*001)
Point Name
5865 Point #
UNUSED
NOTIF
NOTIF OUT,
CTRL CKT Group # (*001)
Point Name
Menu Options/Defaults Comments
